日本进口晶振,SSX-750P,西铁城,SSX-750PBB32000000T,32MHz,7050振荡器
频率:32MHz
尺寸:7.00mm x 5.00mm
日本进口晶振,SSX-750P,西铁城,SSX-750PBB32000000T,32MHz,7050振荡器
SSX-750PBB32000000T是日本进口晶振,为西铁城中的SSX-750P系列晶振。该晶振的频率是32MHz,电压为3.3V,频率稳定度是±50ppm,电流为28mA,工作温度是-20~70度,其尺寸为7.0 x 5.0 x 1.6mm,是属于有源晶振,一般也叫7050振荡器。7050石英晶振采用的是金属面编带封装,具备充分的封密性能,可采用自动贴片机高速焊接,7050贴片晶振在现如今来说,算一款体积较大的贴片晶振,但市场上仍然是不可缺少7050石英晶振。
日本进口晶振,SSX-750P,西铁城,SSX-750PBB32000000T,32MHz,7050振荡器
SSX-750PBB32000000T是日本进口晶振,为西铁城中的SSX-750P系列晶振。该晶振的频率是32MHz,电压为3.3V,频率稳定度是±50ppm,电流为28mA,工作温度是-20~70度,其尺寸为7.0 x 5.0 x 1.6mm,是属于有源晶振,一般也叫7050振荡器。7050晶振采用的是金属面编带封装,具备充分的封密性能,可采用自动贴片机高速焊接,7050贴片晶振在现如今来说,算一款体积较大的贴片晶振,但市场上仍然是不可缺少7050石英晶振。
有源晶振是指晶体本身起振需要外部电压供应,起振后可直接驱动CMOS 集成电路,产品本身已实现与薄型IC(TSSOP封装,TVSOP封装)同样的1mm厚度,断开时的消费电流是15 µA以下,编带包装方式可对应自动搭载及IR回流焊接(无铅对应)产品有几种电压供选1.8V,2.5V,3V3.3V,5V,以应对不同IC产品需要。
日本进口晶振,SSX-750P,西铁城,SSX-750PBB32000000T,32MHz,7050振荡器
品牌 | CITIZEN |
编码 | SSX-750PBB32000000T |
型号 | SSX-750P |
频率 | 32MHz |
频率稳定度 | ±50ppm |
电压 | 3.3V |
尺寸 | 7.00mm x 5.00mm |
工作温度 | -20°C~70°C |
电流 | 28mA |
日本进口晶振,SSX-750P,西铁城,SSX-750PBB32000000T,32MHz,7050振荡器
更多相关晶振参考
原厂代码 | 品牌 | 型号 | 类型 | 频率 | 电压 |
CSX750PCC6.1760MT | CITIZEN晶振 | CSX-750P | XO | 6.176MHz | 5V |
CSX750PCC24.7040MT | CITIZEN | CSX-750P | XO | 24.704MHz | 5V |
CSX750PCC19.4400MT | CITIZEN | CSX-750P | XO | 19.44MHz | 5V |
CSX750PCC15.3600MT | CITIZEN | CSX-750P | XO | 15.36MHz | 5V |
CSX750PCC60.0000MT | CITIZEN | CSX-750P | XO | 60MHz | 5V |
CSX750PCC12.3520MT | CITIZEN | CSX-750P | XO | 12.352MHz | 5V |
CSX750PCC72.0000MT | CITIZEN | CSX-750P | XO | 72MHz | 5V |
CSX750PCC16.3840MT | CITIZEN | CSX-750P | XO | 16.384MHz | 5V |
CSX750PCC33.3330MT | CITIZEN | CSX-750P | XO | 33.333MHz | 5V |
CSX750PCC66.6666MT | CITIZEN | CSX-750P | XO | 66.6666MHz | 5V |
CSX750PCC49.1520MT | CITIZEN | CSX-750P | XO | 49.152MHz | 5V |
CSX750PCC1.5440MT | CITIZEN | CSX-750P | XO | 1.544MHz | 5V |
CSX750PCC1.8432MT | CITIZEN | CSX-750P | XO | 1.8432MHz | 5V |
CSX750PCC3.6864MT | CITIZEN | CSX-750P | XO | 3.6864MHz | 5V |
CSX750PCC4.0000MT | CITIZEN | CSX-750P | XO | 4MHz | 5V |
CSX750PCC7.3728MT | CITIZEN | CSX-750P | XO | 7.3728MHz | 5V |
CSX750PCC8.0000MT | CITIZEN | CSX-750P | XO | 8MHz | 5V |
CSX750PCC10.0000MT | CITIZEN | CSX-750P | XO | 10MHz | 5V |
CSX750PCC12.0000MT | CITIZEN | CSX-750P | XO | 12MHz | 5V |
CSX750PCC12.2880MT | CITIZEN | CSX-750P | XO | 12.288MHz | 5V |
CSX750PCC14.31818MT | CITIZEN | CSX-750P | XO | 14.31818MHz | 5V |
CSX750PCC16.0000MT | CITIZEN | CSX-750P | XO | 16MHz | 5V |
CSX750PCC18.4320MT | CITIZEN | CSX-750P | XO | 18.432MHz | 5V |
CSX750PCC20.0000MT | CITIZEN | CSX-750P | XO | 20MHz | 5V |
CSX750PCC24.0000MT | CITIZEN | CSX-750P | XO | 24MHz | 5V |
CSX750PCC25.0000MT | CITIZEN | CSX-750P | XO | 25MHz | 5V |
CSX750PCC29.4912MT | CITIZEN | CSX-750P | XO | 29.4912MHz | 5V |
CSX750PCC30.0000MT | CITIZEN | CSX-750P | XO | 30MHz | 5V |
CSX750PCC32.0000MT | CITIZEN | CSX-750P | XO | 32MHz | 5V |
CSX750PCC32.7680MT | CITIZEN | CSX-750P | XO | 32.768MHz | 5V |
CSX750PCC40.0000MT | CITIZEN | CSX-750P | XO | 40MHz | 5V |
CSX750PCC44.7360MT | CITIZEN | CSX-750P | XO | 44.736MHz | 5V |
CSX750PCC45.0000MT | CITIZEN | CSX-750P | XO | 45MHz | 5V |
CSX750PCC50.0000MT | CITIZEN | CSX-750P | XO | 50MHz | 5V |
CSX750PCC51.8400MT | CITIZEN | CSX-750P | XO | 51.84MHz | 5V |
CSX750PCC64.0000MT | CITIZEN | CSX-750P | XO | 64MHz | 5V |
CSX750PCC80.0000MT | CITIZEN | CSX-750P | XO | 80MHz | 5V |
SSX-750PCC8000000T | CITIZEN | SSX-750P | XO | 8MHz | 5V |
SSX-750PCC20000000T | CITIZEN | SSX-750P | XO | 20MHz | 5V |
SSX-750PCC1843200T | CITIZEN | SSX-750P | XO | 1.8432MHz | 5V |
SSX-750PCC10000000T | CITIZEN | SSX-750P | XO | 10MHz | 5V |
SSX-750PBB9833000T | CITIZEN | SSX-750P | XO | 9.833MHz | 3.3V |
SSX-750PBB32000000T | CITIZEN | SSX-750P | XO | 32MHz | 3.3V |
SSX-750PBB50000000T | CITIZEN | SSX-750P | XO | 50MHz | 3.3V |
SSX-750PBC4915200T | CITIZEN | SSX-750P | XO | 4.9152MHz | 3.3V |
SSX-750PBC30000000T | CITIZEN | SSX-750P | XO | 30MHz | 3.3V |
SSX-750PBC33333300T | CITIZEN | SSX-750P | XO | 33.3333MHz | 3.3V |
SSX-750PBC66000000T | CITIZEN | SSX-750P | XO | 66MHz | 3.3V |
SSX-750PBF30000000T | CITIZEN | SSX-750P | XO | 30MHz | 3.3V |
SSX-750PBF48000000T | CITIZEN | SSX-750P | XO | 48MHz | 3.3V |
SSX-750PCB96000000T | CITIZEN | SSX-750P | XO | 96MHz | 5V |
SSX-750PCF28330000T | CITIZEN | SSX-750P | XO | 28.33MHz | 5V |
SSX-750PCF66000000T | CITIZEN | SSX-750P | XO | 66MHz | 5V |
SSX-750PDC14400000T | CITIZEN | SSX-750P | XO | 14.4MHz | 5V |
SSX-750PCC12288000T | CITIZEN | SSX-750P | XO | 12.288MHz | 5V |
SSX-750PBB100000000T | CITIZEN | SSX-750P | XO | 100MHz | 3.3V |
SSX-750PBC80000000T | CITIZEN | SSX-750P | XO | 80MHz | 3.3V |
SSX-750PBE16777216T | CITIZEN | SSX-750P | XO | 16.777216MHz | 3.3V |
